Hello, meatbags! Perhaps you saw me at Maker Faire, jukin and jivin and havin a time. You probably wondered “where did this guy get his slick get-up?” And, “is it possible for me to build something similar in his glorious image?” And then your dreams were consumed each night by a vivid nightmare of a distant planet, covered in entirely in evergreen trees and a deafening roar. “What is this place, and why am I forced to wander it every night?” No? Well consider yourself one of the lucky ones then.
Anyway, this is part one of the build log for the Hivelord costume. The inspiration was based on the scramblesuit from the novel A Scanner Darkly, by Philip K Dick, which is a suit that anonymizes its user by constantly projecting a changing image of different people on the outside of the suit. I figured that’s not technologically feasible, but making a mask version certainly is. I originally wanted to record short videos of the inside of the mask, with different people wearing it, but as I built the mask it became obvious that it wouldn’t be feasible, or as cool as using it to take photos. There is a raspberry pi running some python code to control the slideshow and picture taking functions along with an arcade button connected to the raspi’s GPIO. Pressing the button puts the screen into preview mode, which shows what the camera is looking at. When the button is released, the picture is taken and added to the slideshow.
Parts list:
raspberry pi with camera
old laptop screen
output converter for the laptop screen
arcade style button
12V lead acid battery
5V step down converter (for raspi)
HDMI cable
military backpack frame
copper pipe
pipe insulation for padding
various nuts and bolts
mirror for periscope
scrap wood, square dowel
orange spandex suit
This first post will focus on creating the screen. I was surprised to find many vendors on ebay selling boards that will convert the proprietary pinout of the laptop board to something useful, such as HDMI or VGA. If you have an old screen laying around, you can even make a new monitor for yourself for $35.
Found an old laptop screen in the hackerspace
Take the case off the screen and read the model number from the back. Look around on ebay for a converter board. It seems like most of them are made to order, so if you don’t find a listing, try contacting a seller. Below is a picture of the board I used, which runs off 12V. Thankfully I found a 12V wall wart in the space to test it.
The deconstructed screenThe screen connector. This will be converted to something useful, like HDMI.
The converter board came with all its own cables and its own separate board to control the screen functions, like resolution, alignment, and an on/off button.
Here’s the pic from the ebay listing. Nifty!
Once everything is plugged in, turn it on to test it out. The screen worked perfectly, and automatically configured itself to the correct resolution. There was enough cabling for me to run the wires outside of the original laptop screen case, so I just put everything back the way it was, with the converter board hanging off. All the electronics will eventually be mounted to the wooden frame of the mask.
First try running the screen.
Next, connect everything together, screen to converter to raspi, and power it up. Here I am testing out the camera after I changed all the settings to portrait mode.
The creator’s visage!
I then connected it all to a bench supply so I could see how much power the whole set up consumed. It uses just about an amp at 12v. I found a 7 amp-hour 12V lead acid battery on amazon that did a decent job, though I’d probably buy a spare since I did run out of battery at maker faire. There’s a 5V downcoverter thrown in there too, to power the raspberry pi off the 12V supply.
Powering up this mess with a sneak peek of the copper frame.
Thanks for reading! Next post will be on the making of the frame.
